P750

Introducing the P750 Centrifugal Compressor by FS-Elliott delivers higher flow capacity beyond existing frames. As the largest Polaris compressor in the product line, the P750 delivers maximum output within a minimized footprint. For facilities seeking a smarter alternative to larger engineered compressor systems, the P750 provides ISO 8573-1 Class 0 oil-free air with exceptional efficiency for the most demanding industrial applications.

With a dependable flow of up to 625 m3/min or 22,100 CFM, the P750 sets the standard for high-capacity compression across a wide range of industrial settings.

Request a Quote View Interactive Model

The P750 centrifugal compressor delivers reliable, 100% oil-free air that meets ISO 8573-1 CLASS 0 standards, ensuring optimal performance for critical operations across various industries. Explore the product brochure for more details.
  • Flow: 360 – 625 m3/min | 128,00 – 22,100 cfm
  • Power: 2,237 – 3,728 kW | 3,000 – 5,000 hp
  • Pressure: 2.75 – 10.3 barg | 40 – 150 psig





P750 Features & Benefits

Superior Reliability
  • Incorporates the highest quality gearing, adhering to AGMA 13 standards.
  • Bull gear shaft-driven MOP guarantees reliable lubrication even under extreme conditions.
  • Utilizes technology akin to gas turbines or aero engines for optimal stability in various operating conditions.
  • Floating dual carbon ring seals minimize leakage, ensuring the highest air quality.
  • Custom vibration-detecting instruments and bearing RTDs monitor and protect the compressor.
  • Control panels offer maintenance notifications and remote monitoring via an IIoT platform.
Energy Efficiency
  • State-of-the-art aerodynamic design based on 60 years of experience.
  • High stage efficiency across a wide turndown range.
  • Supports heat of compression (HOC) drying technology for addtional energy savings.
  • Patented control modes optimize energy consumption based on job site conditions.
  • FS-Connect's Energy Advisor continuously monitors performance and delivers data-driven recommendations to maximize energy savings.
Ease of Operation & Maintenance
  • Plug-and-play design with a large touchscreen HMI for easy installation and operation.
  • PLC-based control system with Siemens or Allen Bradley platform and popular instrumentation and communication options.
  • Split gear case and bearing design allow quick maintenance without rotor removal.

Case Study: Industrial Gas Producer Reduced Capital Expenditures & Increased Efficiency


  1. Case Study

    Learn how an industrial gas producer reduced capital expenditures and increased overall efficiency.

    View full case study.

  2. Background

    An industrial gas producer opened a new air separation plant that required 4440 Nm3/h of air and 2100 Nm3/h of gaseous nitrogen for production.

    View full case study.

  3. Manufacturing Challenge

    Due to the modular design of the plant, the compressors selected for the project needed to be minimal in size but capable of high-efficiency gas production.

    View full case study.

  4. Results

    Customer reduced capital expenditures and increase overall efficiency by combining the air and nitrogen processes in one machine.

    View full case study.

Learn how an industrial gas producer reduced capital expenditures and increased overall efficiency.

View full case study.

P750 Options & Accessories

  • Axial Probe
    Axial Probe

    Senses shaft end position and/or thrust collar position and notifies operator via the control panel should the rotor assembly move beyond the alarm or trip set points.

  • Condensate Drain
    Condensate Drain

    Provides a regulated discharge of condensate and eliminates the loss of compressed air.

  • Control Systems
    Control Systems

    Featuring the most powerful processors in the industry, the Regulus line offers unprecedented compressor control, providing reliable, efficient operations and substantial energy savings.

  • Control Valves
    Control Valves

    Production areas use air operated valves and cylinders.

  • Drain Valve
    Drain Valve

    Only discharges condensate when the reservoir is full, eliminating water without losing air.

  • Dual Oil Filters
    Dual Oil Filters

    Allows continuous operation while switching smoothly from one element to the other.

  • FS-Connect
    FS-Connect

    FS-Connect has been designed to give you visibility of the operational status and performance of your FS-Elliott air compressor.

    Learn More

  • FSE-TurboCool
    FSE-TurboCool

    Lubricants and additives designed to minimize harmful buildup and maximize equipment operating cycles.

    Learn More

  • Motor Starters
    Motor Starters

    Choose from a full line of motor starters to suit your needs. Certain models include an option to mount the starter to the unit.
